Air Bags B20 MOA Twin Bellow (Single Port) Dual Pack (1x Pair)
The Ultimate in Air Ride Suspension Parts
The MOA B20 Air Bag, features a maximum restrained pressure exceeding all on the market still holding at 600PSI, sidewall holding at below 7″ operating pressure.
The Ultra Strong construction will maintain a narrow expansion body at all operating pressures. Webbed internal and external construction featuring a square sidewall. The rubber compound is over 4x thickness of equivalent dimension air bags. This bag is often used for A-frame custom contructions, heavy lift applications and load level.
Safe cycling upto 250PSI.
Pressure (Bar)1357
External Diameter158.2mm162.3mm165.5mm168.5mm
Load (KN)1.6044.1206.7209.380
Details:
Maximum Extended Height: 10.6″
Compressed Height: 2.8″
Maximum Diameter: 7″
Maximum Load at 100 PSI: 2,108 lbs.
Port Size: 1/2″
Top Fastener: 3/8″–16
Bottom Fastener: 3/8″–16
Mounting Hole Center: 1.75″ – Top/Center/Bottom
Product Code: 30010144
OE Code:
